Motorcycle Dashboard
The N9H series microprocessor platform supports Non-OS, RT-Thread, FreeRTOS operating systems, and provides emWin(*1) and LVGL graphics library to develop dashboard graphics for free. In addition, users can reference to Nuvoton motorcycle dashboard demo for speed up the development.
N9H Series MPU platform and the motorcycle dashboard demo included features:
- Fast booting within 1 sec
- Integrated 2D GFx, H.264 and JPEG decoder for smooth TFT-LCD display.(*2)
- Rich peripherals fulfill the Specification requirement
(Rich peripherals fulfill the specification requirements, such as SPI-NOR or NAND flash, CAN-Bus, ADC, SDIO etc.) - Integrated high-capacity DDR for a fancy GUI and saving BOM cost
- Industrial grade operating temp. form -40°C to 85°C.(*3)
*1. Nuvoton is licensed with SEGGER emWin graphics library; users can use it for free on Nuvoton HMI platforms.
*2. N9H26 integrated H.264 video decoder
*3. N9H30 is industrial grade IC
N9H Series MPU EVB
|
EVB Part no. |
CPU Frequency |
DDR |
EVB TFT-LCD resolution |
|---|---|---|---|
|
300 MHz |
64 MB |
800 x 480 |
|
|
240 MHz |
64 MB |
800 x 480 |
|
|
200 MHz |
32 MB |
480 x 272 |
This Nuvoton motorcycle dashboard demo is implemented on NuMaker-HMI-N9H30 EVB, which with 7” 800x480 TFT-LCD
Download the template (Github)
Nuvoton N9H Series MPU for Motorcycle Dashboard eDM
