EPS Global, one of the world’s largest Programming and Secure Provisioning service providers, announced that it has joined Nuvoton’s Security Partner Ecosystem, making its secure provisioning services available to Nuvoton customers worldwide.

Since security and power consumption are key requirements in IoT applications, Nuvoton has developed security-enabled MCUs which provide chip-level physical security with ultra-low-power performance. Through EPS, Nuvoton’s customers can seamlessly access a global network of secure programming centers to service their data programming and secure provisioning requirements for Nuvoton devices, from prototypes to high volume.

Nuvoton NuMicro ML54 series is a low-power microcontroller, based on 1T 8051 core, embedded 64 KB flash and 4 KB SRAM, built-in LCD driver, running up-to 24 MHz. For low power operation, it runs less than 100 µA/MHz in normal run mode, and the power-down current is below 2 µA with LCD panel display on. The ML54 series operates from 1.8V to 3.6V and-40°C to 105°C.

NuMicro ML54 series builts in 4 COM x 32 SEG, 6 COM x 30 SEG, 8 COM x 28 SEG LCD controller to drive up to 224 dots, and supports the Type-A and Type-B LCD panel. It provides two V_LCD input sources, one is external voltage, and another is an internal charge pump, The internal charge pump keeps the V_LCD constant voltage to maintain the display quality of the LCD panel while V_DD input changes. There are two V_LCD driving modes, external capacitor mode, and internal resistor mode. The external capacitor mode with up to 200mA strong driving current to support a large size panel; the internal resistor mode drives a small size panel and reduces power consumption.

Nuvoton NuMicro®ML56 series is a low-power microcontroller, based on 1T 8051 core, embedded 64 KB flash and 4 KB SRAM, built-in capacitive touch key and LCD driver, running up to 24 MHz. For low power operation, it runs less than 100 µA/MHz in normal run mode, and the power-down current is below 2 µA with LCD panel display on. The ML56 series operates from 1.8V to 3.6V and -40°C to 105°C.

NuMicro® ML56 series integrated capacitive touch sensing circuit with enhanced touch key controller, supporting up to 14 independent touch channels with low power characteristics, waterproof, and high noise resistance features.  The touch key can be one of the wake up source and has conducted 10-Vrms noise immunity, which makes it especially suitable for home appliances and industrial control. Moreover, Nuvoton provides a complete development tool, and touch library to shorten customer’s development and mass production by easy calibration of touch key functions.

Nuvoton Technology launches a new NuMicro^® M031BT series: An low-power BLE 5.0 and 2.4GHz dual-mode microcontroller series by Arm^® Cortex^®-M0 core operating up to 48 MHz, with up to 128 KB Flash and 16 KB SRAM. In addition to the BLE 5.0 and 2.4GHz RF functions providing wireless connectivity, the NuMicro^® M031BT series built-in rich peripherals and analog functions applied to the applications that need IO control functions, such as industrial control that need wireless connectivity, sensor hubs in rigid working environments. The 5mm x 5mm QFN48 package greatly reduces the PCB size and RF layout difficulty, and Nuvoton provides a reference design and rich sample codes to speed up the application development based on this M031BT low-power BLE/2.4G RF microcontroller.

The industrial-grade NuMicro M251/ M252 series designed for industrial control applications. It is based on Arm Cortex-M23 secure core for Armv8-M architecture, running up to 48 MHz with up to 256 KB Flash and up to 32 KB SRAM. The power consumption in the deep power-down mode is down to 2.0 μA; NuMicro M251/M252 Series provides five kinds of power modes and three kinds of secure protect mechanisms to satisfy the sensor node devices which cares power consumption in IIoT applications.

The NuMicro^® M261 / M262 / M263 series is a low-power microcontroller platform based on Arm® Cortex®-M23 core for Armv8-M architecture. It runs up to 64 MHz with 512 Kbytes embedded Flash memory in dual bank mode supporting Over-The-Air ( OTA ) firmware update and 96 Kbytes embedded SRAM. It also supports low supply voltage from 1.8 ~ 3.6V and operating temperature range from - 40 ~ + 105 ℃

Webinars, latest tutorial videos, latest technical articles/ reference applications, and shop Nuvoton products online

NuMicro® MS51 industrial series microcontrollers is based on 1T 8051 core, running up to 24 MHz, with up to 32 Kbyte of Flash memory and up to 2 Kbyte of SRAM. It supports one high precision 24 MHz allowing ± 1 % deviation and one 10 kHz internal RC Oscillators, operating at 2.4V ~ 5.5V voltage and - 40 ℃ ~ 105 ℃.

The NuMicro® M483 CAN series is a high performance, low power microcontroller powered by the Arm® Cortex®-M4F core with DSP extension. It can run up to 192 MHz with 175 µA/ MHz dynamic low power consumption. The 512/ 256 KB embedded dual bank Flash memory supports OTA ( Over-The-Air ) firmware upgrade, and the 160/ 96 KB embedded SRAM includes 32 KB cache to speed up external SPI Flash code execution. The factory pre-loaded bootloader delivers Secure Boot functionality to provide the code integrity check in embedded Flash memory. The built-in Secure Protection ROM provides a safe space for saving confidential program or data. One-Time Programmable ROM is also included for product life-cycle management.
