Small Size MOSFET for General Switching

Feature

1.Designability
Ultra small size; 0.6 x 0.6mm
2.Low noise/ Ringing suppression
Low inductance; 99% less than Mold package
3.High reliability
Low failure rate; 0PPM _{(Based on Nuvoton QA records)}

VDS 12V

Parts number	Data sheet	Type	VDS [V]	VGS [V]	ID*1 [A]	Rss(on)Typ.[mΩ]				Package Size[mm]
Parts number	Data sheet	Type	VDS [V]	VGS [V]	ID*1 [A]	VGS 4.5V	VGS 2.5V	VGS 1.8V	VGS 2.5V	x	y	t
KFJ4B01110L		P-Single	-12	±8	-2.2	118	114	169	199	0.6	0.6	0.1
KFJ4B01100L		P-Single	-12	±8	-3.3	57	68	82	97	0.8	0.8	0.1
KFJ4B01120L		P-Single	-12	±8	-4.2	34	40	48	57	1	1	0.1

＊1 FR4 board (25.4mm×25.4mm×t1.0mm), Full Cu
