Low On Resistance MOSFET for Li-ion Battery Protection
 |
 |
|
Feature
1.Long battery run time and fast charging
Low on resistance; 1.1 mΩ
2.Designability
Ultra small size; 0.6 x 0.6 mm
3.Prevent deep discharge
Low leakage; IGSS = 0.1 uA
4.High safety
Low failure rate; 0 PPM (Based on Nuvoton QA records) |
|
|
VSS 12V/ Nch Dual
| Parts number |
Data sheet |
Type |
VSS
[V] |
VGS
[V] |
IS*1
[A] |
Rss(on)Typ.[mΩ] |
Package Size[mm] |
VGS
4.5V |
VGS
3.8V |
VGS
3.1V |
VGS
2.5V |
x |
y |
t |
| KFCAB21860L |
|
N-Dual |
12 |
±8 |
17 |
1.35 |
1.5 |
1.7 |
2.25 |
2.52 |
2.3 |
0.095 |
| KFCAB21520L |
|
N-Dual |
12 |
±8 |
16 |
1.45 |
1.6 |
1.8 |
2.3 |
3.54 |
1.77 |
0.11 |
| KFCAB21890L |
|
N-Dual |
12 |
±8 |
14.5 |
1.75 |
1.95 |
2.25 |
2.9 |
2.98 |
1.49 |
0.075 |
| KFCAB21770L |
|
N-Dual |
12 |
±8 |
14.5 |
1.8 |
2 |
2.2 |
2.7 |
3.54 |
1.77 |
0.11 |
| KFCAB21260L |
|
N-Dual |
12 |
±8 |
12 |
2 |
2.2 |
2.4 |
3.1 |
3.54 |
1.77 |
0.11 |
| KFCAB21740L |
|
N-Dual |
12 |
±8 |
13.6 |
2.1 |
2.2 |
2.6 |
3.5 |
1.96 |
1.84 |
0.08 |
| KFCAB21350L |
|
N-Dual |
12 |
±8 |
12 |
2.1 |
2.2 |
2.4 |
3.1 |
3.05 |
1.77 |
0.11 |
| KFCAB21490L |
|
N-Dual |
12 |
±8 |
13.5 |
2.1 |
2.2 |
2.4 |
3.1 |
2.98 |
1.49 |
0.11 |
| KFCAB21A50L |
|
N-Dual |
12 |
±8 |
13.5 |
2.1 |
2.2 |
2.4 |
3.1 |
2.98 |
1.49 |
0.11 |
| KFC6B21150L |
|
N-Dual |
12 |
±10.5 |
8 |
4 |
4.3 |
4.8 |
5.9 |
2.14 |
1.67 |
0.11 |
| KFC6B21810L |
|
N-Dual |
12 |
±8 |
9 |
4.2 |
4.6 |
5.4 |
7.4 |
1.89 |
1.24 |
0.08 |
| KFC4B21210L |
|
N-Dual |
12 |
±8 |
4.7 |
12 |
13 |
14 |
17 |
1.29 |
1.29 |
0.1 |
| KFC4B21220L |
|
N-Dual |
12 |
±8 |
3 |
21 |
23 |
26 |
33 |
0.97 |
0.97 |
0.1 |
| KFC4B21080L |
|
N-Dual |
12 |
±12 |
2.9 |
27 |
30 |
39 |
60 |
1.11 |
1.11 |
0.1 |
| KFC4B21320L |
|
N-Dual |
12 |
±8 |
2.5 |
36 |
39 |
45 |
58 |
0.8 |
0.8 |
0.1 |
| KFC4A21300L |
|
N-Dual |
12 |
±8 |
1.5 |
70 |
80 |
90 |
115 |
0.6 |
0.6 |
0.2 |
| KFC4B21300L |
|
N-Dual |
12 |
±8 |
1.5 |
70 |
80 |
90 |
115 |
0.6 |
0.6 |
0.1 |
| KFC4B21330L |
|
N-Dual |
12 |
±8 |
1.5 |
95 |
100 |
115 |
145 |
0.8 |
0.8 |
0.1 |
＊1 FR4 board (25.4mm×25.4mm×t1.0mm), Full Cu
|
|
VSS 20V-24V/ Nch Dual
| Parts number |
Data sheet |
Type |
VSS
[V] |
VGS
[V] |
IS*1
[A] |
Rss(on)Typ.[mΩ] |
Package Size[mm] |
VGS
4.5V |
VGS
3.8V |
VGS
3.1V |
VGS
2.5V |
x |
y |
t |
| KFCAB22370L |
|
N-Dual |
20 |
±12 |
10 |
3.1 |
3.3 |
3.8 |
4.6 |
3.05 |
1.77 |
0.11 |
| KFC6B22160L |
|
N-Dual |
±8 |
8 |
4.7 |
4.9 |
5.2 |
6 |
2.65 |
1.67 |
0.11 |
| KFC4B22180L |
|
N-Dual |
±8 |
5 |
9.4 |
10 |
11.1 |
13.4 |
1.74 |
1.74 |
0.11 |
| KFC4B22270L |
|
N-Dual |
±12 |
4 |
17 |
18 |
19 |
22 |
1.29 |
1.29 |
0.1 |
| KFC4B22690L |
|
N-Dual |
±12 |
3.4 |
28 |
30.5 |
33 |
36 |
1.1 |
1.1 |
0.1 |
| KFC4B22670L |
|
N-Dual |
±12 |
2.9 |
35 |
37.5 |
42 |
64 |
1.1 |
1.1 |
0.1 |
| KFCAB22630L |
|
N-Dual |
23 |
±12 |
13.8 |
2.2 |
2.4 |
2.8 |
5 |
3.4 |
1.96 |
0.095 |
| KFCAB22680L |
|
N-Dual |
±12 |
13 |
2.45 |
2.65 |
3 |
3.85 |
3.2 |
2.1 |
0.095 |
| KFC6B22100L |
|
N-Dual |
24 |
±12 |
6 |
8.2 |
8.7 |
9.7 |
12.5 |
2.56 |
1.67 |
0.1 |
| KFC6B22220L |
|
N-Dual |
±12 |
13*2 |
8.2 |
8.7 |
9.7 |
12.5 |
2.56 |
1.67 |
0.1 |
| KFC6B22090L |
|
N-Dual |
±12 |
12*2 |
8.5 |
9 |
10 |
13 |
2.56 |
1.67 |
0.1 |
| KFC4B22070L |
|
N-Dual |
±12 |
3.5 |
17.5 |
- |
20 |
23 |
1.67 |
1.67 |
0.1 |
*1 FR4 board (25.4mm×25.4mm×t1.0mm), Full Cu
*2 Mounted on Ceramic substrate (70mm x 70mm x t1.0mm) |
|
VSS 30V/ Nch Dual
| Parts number |
Data sheet |
Type |
VSS
[V] |
VGS
[V] |
IS*1
[A] |
Rss(on)Typ.[mΩ] |
Package Size[mm] |
VGS
4.5V |
VGS
3.8V |
VGS
3.1V |
VGS
2.5V |
x |
y |
t |
| KFC7P23440L |
|
N-Dual |
30 |
±20 |
19 |
3.4 |
ー |
ー |
ー |
6 |
3 |
0.345 |
＊1 FR4 board (25.4mm×25.4mm×t1.0mm), Full Cu |
